CCNA 200-301 Book

Answer as below configuration:

Sw1

enbale

config t

Vlan 210

Name FINANCE

Inter e0/1

Switchport access vlan 210

do wr

Sw2

Enable

config t

Vlan 110

Name MARKITING

Int e0/1

Switchport acees vlan 110

do wr

Sw3

Enable

config t

Vlan 110

Name MARKITING

Vlan 210

Name FINANCE

Int e0/0

Switchport access vlan 110

Int e0/1

Switchport access vlan 210

Sw1

Int e0/1

Switchport allowed vlan 210

Sw2

Int e0/2

Switchport trunk allowed vlan 210

Sw3

Int e0/3

Switchport trunk allowed vlan 210

Switchport trunk allowed vlan 210,110

four. Automation questions depend on recognizing controllers, APIs, data formats, HTTP methods, and cloud-service characteristics. Cisco CCNA 200-301 v1.1 includes this under Automation and Programmability, where the expected skill is identifying the mechanism that actually satisfies the scenario. The wording usually gives the decisive clue: a protocol number, a route prefix, a control-plane role, a wireless security method, or a management command. The wrong options mix controller functions with data-plane forwarding or confuse API operations with unrelated management terms. In a real network, selecting the wrong option would usually produce a failed adjacency, broken client connectivity, insecure management access, or an incorrect forwarding path. The selected answer matches the Cisco behavior and configuration model required by the question, so it is retained as the verified answer for this item.

snmp-server user. SNMPv3 introduces user-based security, authentication, and optional encryption. The command snmp-server user is therefore the command that implies SNMPv3 because users are created for SNMPv3 security models. The snmp-server community command is associated with SNMPv1 and SNMPv2c community strings, which are weaker and do not provide the same authentication and privacy capabilities. The snmp-server host and snmp-server enable traps commands can be used in broader SNMP configurations, but they do not by themselves identify SNMPv3. Cisco CCNA 200-301 v1.1 IP Services expects engineers to know that SNMPv3 is the secure version preferred for device monitoring. The original community-string answer was wrong and has been corrected to snmp-server user.

Option. The requirements are restrictive: only Telnet is allowed, the enable password must be entered as plain text in the configuration command, and it must still be stored securely. The enable secret command with a 0 keyword accepts the following password as clear text at entry time and then stores it as a secret hash. The VTY lines must use login local and transport input telnet to permit only Telnet after local authentication. The options that use enable password do not store the privileged password securely, and transport input all permits more than Telnet. Cisco CCNA 200-301 v1.1 Security Fundamentals expects engineers to distinguish enable password from enable secret and to understand VTY transport restrictions. The corrected answer is Option A.
