Implementing Cisco Enterprise Advanced Routing and Services (300-410 ENARSI) Questions and Answers

Question 81

Refer to the exhibit.

Although summarization is configured for R1 to receive 10.0.0.0/8. more specific routes are received by R1. How should the 10.0.0.0/8 summary route be received from the neighbor, attached to R1 via Fast Ethernet0/0 interface?

Options:

A.

R1 should configure the ip summary-address eigrp 10.0.0.0.255.0.0.0 command under the Fast Ethernet 0/0 interface.

B.

The summarization condition is not met Router 10 1 100.10 requires a route for 10 0.0.0/8 that points to null 0

C.

The summarization condition is not met. The network 10.1.100.0/24 should be changed to 172.16.0.0/24.

D.

R1 should configure the ip summary-address eigrp 10.0.0.0 0.0.0.255 command under the Fast Ethernet 0/0 interface.

Question 82

Refer to the exhibit.

The administrator noticed that the connection was flapping between the two ISPs instead of switching to ISP2 when the ISP1 failed. Which action resolves the issue?

Options:

A.

Include a valid source-interface keyword in the icmp-echo statement.

B.

Reference the track object 1 on the default route through ISP2 instead of ISP1.

C.

Modify the static routes to refer both to the next hop and the outgoing intertace.

D.

Modify the threshold to match the administrative distance of the ISP2 route.

Question 83

The network administrator configured CoPP so that all HTTP and HTTPS traffic from the administrator device located at 172.16 1.99 toward the router CPU is limited to 500 kbps. Any traffic that exceeds this limit must be dropped.

access-list 100 permit ip host 172.16.1.99 any

!

class-map CM-ADMIN

match access-group 100

!

policy-map PM-COPP

class CM-ADMIN

police 500000 conform-action transmit

!

interface E0/0

service-policy input PM-COPP

CoPP failed to capture the desired traffic and the CPU load is getting higher.

Which two configurations resolve the issue? (Choose two.)

Options:

A.

interface E0/0no service-policy input PM-COPP!control-planeservice-policy input PM-COPP

B.

policy-map PM-COPPclass CM-ADMINno police 500000 conform-action transmitpolice 500 conform-action transmit!control-planeservice-policy input PM-COPP

C.

no access-list 100access-list 100 permit tcp host 172.16.1.99 any eq 80

D.

no access-list 100access-list 100 permit tcp host 172.16.1.99 any eq 80access-list 100 permit tcp host 172.16.1.99 any eq 443

E.

policy-map PM-COPPclass CM-ADMINno police 500000 conform-action transmitpolice 500 conform-action transmit

Question 84

What is a characteristic of Layer 3 MPLS VPNs?

Options:

A.

LSP signaling requires the use of unnumbered IP links for traffic engineering.

B.

Traffic engineering supports multiple IGP instances

C.

Traffic engineering capabilities provide QoS and SLAs.

D.

Authentication is performed by using digital certificates or preshared keys.
