Implementing Cisco Enterprise Advanced Routing and Services (300-410 ENARSI) Questions and Answers

Question 133

Refer to Exhibit.

The network administrator configured the branch router for IPv6 on the E0/0 interface. The neighboring router is fully configured to meet requirements, but the neighbor relationship is not coming up. Which action fixes the problem on the branch router to bring the IPv6 neighbors up?

Options:

A.

Enable the IPv4 address family under the router ospfv3 4 process by using the address-family ipv4 unicast command

B.

Disable IPv6 on the E0/0 interface using the no ipv6 enable command

C.

Enable the IPv4 address family under the E0/0 interface by using the address-family ipv4 unicast command

D.

Disable OSPF for IPv4 using the no ospfv3 4 area 0 ipv4 command under the E0/0 interface

Question 134

Exhibit:

Bangkok is using ECMP to reach to the 192.168.5.0/24 network. The administrator must configure Bangkok in such a way that Telnet traffic from 192.168.3.0/24 and192.168.4.0/24 networks uses the HongKong router as the preferred router. Which set of configurations accomplishes this task?

Options:

A.

access-list 101 permit tcp 192.168.3.0 0.0.0.255 192.168.5.0 0.0.0.255access-list 101 permit tcp 192.168.4.0 0.0.0.255 192.168.5.0 0.0.0.255!route-map PBR1 permit 10match ip address 101set ip next-hop 172.18.1.2interface Ethernet0/3ip policy route-map PBR1

B.

access-list 101 permit tcp 192.168.3.0 0.0.0.255 192.168.5.0 0.0.0.255 eq 23access-list 101 permit tcp 192.168.4.0 0.0.0.255 192.168.5.0 0.0.0.255 eq 23!route-map PBR1 permit 10match ip address 101set ip next-hop 172.18.1.2interface Ethernet0/1ip policy route-map PBR1

C.

access-list 101 permit tcp 192.168.3.0 0.0.0.255 192.168.5.0 0.0.0.255 eq 23access-list 101 permit tcp 192.168.4.0 0.0.0.255 192.168.5.0 0.0.0.255 eq 23!route-map PBR1 permit 10match ip address 101set ip next-hop 172.18.1.2!interface Ethernet0/3ip policy route-map PBR1

D.

access-list 101 permit tcp 192.168.3.0 0.0.0.255 192.168.5.0 0.0.0.255access-list 101 permit tcp 192.168.4.0 0.0.0.255 192.168.5.0 0.0.0.255!route-map PBR1 permit 10match ip address 101set ip next-hop 172.18.1.2!interface Ethernet0/1ip policy route-map PBR1

Question 135

Refer to the exhibit.

A user has set up an IP SLA probe to test if a non-SLA host web server on IP address 10.1.1.1 accepts HTTP sessions prior to deployment. The probe is failing. Which action should the network administrator recommend for the probe to succeed?

Options:

A.

Re-issue the ip sla schedule command.

B.

Add icmp-echo command for the host.

C.

Add the control disable option to the tcp connect.

D.

Modify the ip sla schedule frequency to forever.

Question 136

When configuring Control Plane Policing on a router to protect it from malicious traffic, an engineer observes that the configured routing protocols start flapping on

that device. Which action in the Control Plane Policy prevents this problem in a production environment while achieving the security objective?

Options:

A.

Set the conform-action and exceed-action to transmit initially to test the ACLs and transmit rates and apply the Control Plane Policy in the output direction

B.

Set the conform-action and exceed-action to transmit initially to test the ACLs and transmit rates and apply the Control Plane Policy in the input direction

C.

Set the conform-action to transmit and exceed-action to drop to test the ACLs and transmit rates and apply the Control Plane Policy m the input direction

D.

Set the conform-action to transmit and exceed-action to drop to test the ACLs and transmit rates and apply the Control Plane Policy m the output direction
