MuleSoft-Platform-Architect-I Exam Dumps : Salesforce Certified MuleSoft Platform Architect (Mule-Arch-201)

Explanation

Correct Answer: Invoke the system API deployed to the primary environment; add timeout and retry logic to the process API to avoid intermittent failures; if it still fails, invoke the system API deployed to the DR environment

*****************************************

There is one important consideration to be noted in the question which is - System API in DR environment provides only 20% of the rate limiting offered by the primary environment. So, comparitively, very less calls will be allowed into the DR environment API opposed to its primary environment. With this in mind, lets analyse what is the right and best fault-tolerant invocation strategy.

1. Invoking both the system APIs in parallel is definitely NOT a feasible approach because of the 20% limitation we have on DR environment. Calling in parallel every time would easily and quickly exhaust the rate limits on DR environment and may not give chance to genuine intermittent error scenarios to let in during the time of need.

2. Another option given is suggesting to add timeout and retry logic to process API while invoking primary environment's system API. This is good so far. However, when all retries failed, the option is suggesting to invoke the copy of process API on DR environment which is not right or recommended. Only system API is the one to be considered for fallback and not the whole process API. Process APIs usually have lot of heavy orchestration calling many other APIs which we do not want to repeat again by calling DR's process API. So this option is NOT right.

3. One more option given is suggesting to add the retry (no timeout) logic to process API to directly retry on DR environment's system API instead of retrying the primary environment system API first. This is not at all a proper fallback. A proper fallback should occur only after all retries are performed and exhausted on Primary environment first. But here, the option is suggesting to directly retry fallback API on first failure itself without trying main API. So, this option is NOT right too.

This leaves us one option which is right and best fit.

- Invoke the system API deployed to the primary environment

- Add Timeout and Retry logic on it in process API

- If it fails even after all retries, then invoke the system API deployed to the DR environment.

Understanding Circuit Breaker Policy:

A circuit breaker is a design pattern used to detect failures and prevent an application from continually trying to execute a failing operation. In this case, it will help improve response time and reduce demand on the downstream API.

The specified configuration includes conditions for opening, half-opening, and closing the circuit based on error rates over time:

Circuit Open: Triggered if there are more than 10 errors per minute for three consecutive minutes.

Circuit Half-Open: The circuit transitions to half-open if there is one error per minute.

Circuit Closed: The circuit closes if the error rate is less than one error per minute for five minutes.

Evaluating the Options:

Option A: Creating a custom policy with template expressions could work, but it would require custom development. Since the Anypoint Platform already has a Circuit Breaker policy available, this would be a less efficient and more complex solution.

Option B: Anypoint Monitoring alerts can be used for monitoring the API, but they do not provide circuit-breaking functionality. Additionally, implementing a retry strategy for the half-open state is not sufficient to achieve the required circuit breaker behavior.

Option C (Correct Answer): Adding the Circuit Breaker policy to the API instance on Anypoint Platform allows you to set up circuit-breaking conditions directly. This approach uses the built-in Circuit Breaker policy, where you can configure parameters such as error thresholds and time intervals to match the requirements. This solution is efficient, reliable, and leverages Anypoint’s out-of-the-box capabilities.

Option D: Implementing the strategy within a Mule application with a YAML configuration could be complex and less manageable. Additionally, it does not leverage Anypoint Platform’s built-in Circuit Breaker policy, which is more suited to this scenario.

Conclusion:

Option C is the correct choice, as it leverages Anypoint Platform’s Circuit Breaker policy. This solution allows for configuring thresholds and time intervals as specified, improving response time and reducing demand on the downstream API while utilizing Anypoint's managed policy feature.

Refer to MuleSoft’s documentation on implementing the Circuit Breaker policy in API Manager for detailed configuration guidance.

When using CloudHub 1.0’s Shared Load Balancer (SLB) for a Mule application configured with HTTPS in an Anypoint VPC, specific ports must be configured for the application to correctly route incoming traffic:

Port Requirement for SLB:

The CloudHub Shared Load Balancer for HTTPS traffic requires that applications listen on port 8092 for secure (HTTPS) communication. This port is reserved specifically for SSL traffic when using SLB with Anypoint VPCs.

Why Option B is Correct:

Setting the HTTP Listener's connector configuration to 8092 aligns with CloudHub requirements for HTTPS via the Shared Load Balancer.

Explanation of Incorrect Options:

Option A (8082) is used for non-HTTPS (HTTP) traffic.

Option C (80) and Option D (443) are standard web ports but are not applicable within CloudHub SLB’s internal configuration for VPC routing.

ReferencesFor more information on the Shared Load Balancer port configurations, refer to MuleSoft’s documentation on CloudHub and VPC load balancer requirements​.
