To monitor Mule applications deployed on customer-hosted Mule runtimes from Anypoint Platform, you need to enable monitoring for each application within the Runtime Manager's application settings. This step ensures that the Runtime Manager Agent, which is already part of the Mule runtime, will collect and send monitoring data to Anypoint Monitoring.

The Runtime Manager Agent acts as the intermediary, collecting metrics and operational data from the Mule applications and transmitting this data to Anypoint Monitoring for analysis and visualization. This setup provides real-time insights and allows for effective monitoring and management of Mule applications.

MuleSoft Documentation on Anypoint Monitoring

Explanation

* Anypoint Runtime Fabric is a container service that automates the deployment and orchestration of your Mule applications and gateways.

* Runtime Fabric runs on customer-managed infrastructure on AWS, Azure, virtual machines (VMs) or bare-metal servers.

* As none of the Mule applications use Mule domain projects. applications are not required to be rewritten. Also when applications are deployed on RTF, by default ingress is allowed only on 8081.

* Hence port conflicts are not required to be managed by DevOps team

Requirement Analysis: The Mule application needs secure access to both an on-premises database and a Kafka cluster in AWS VPC.

Solution: Setting up Anypoint VPN for the on-premises corporate data center and VPC peering with AWS VPC ensures secure and seamless connectivity.

Implementation Steps:

Anypoint VPN Setup:

In the Anypoint Platform, navigate to the VPN configuration.

Create a new VPN connection between the CloudHub VPC and the on-premises corporate data center.

Configure the necessary VPN parameters such as IP address, shared secret, and routing information.

Establish the VPN tunnel and verify connectivity.

VPC Peering Setup:

In the AWS Management Console, navigate to the VPC dashboard.

Create a VPC peering connection between the AWS VPC (where Kafka is hosted) and the CloudHub VPC.

Configure the necessary route tables to allow traffic between the peered VPCs.

Verify the peering connection and ensure that the routing is correctly set up to allow communication between the Mule application and the Kafka cluster.

Testing: Conduct thorough testing to ensure the Mule application can securely connect to both the on-premises database and the Kafka cluster in AWS.

Advantages:

Security: Ensures secure communication channels between CloudHub VPC, on-premises data center, and AWS VPC.

Reliability: Provides a robust and reliable network setup for accessing critical infrastructure components.

References

MuleSoft Documentation on Anypoint VPN

AWS Documentation on VPC Peering
