Microsoft Azure AZ-400 Updated Exam

Step 1: To create a general-purpose v2 storage account in the Azure portal, follow these steps:

On the Azure portal menu, select All services. In the list of resources,type Storage Accounts. As you begin typing, the list filters based on your input. Select Storage Accounts.

On the Storage Accounts window that appears, choose Add.

Select the subscription in which to create the storage account.

Under the Resource group field, select RG1lod11566895

Next, enter a name for your storage account named: az400lod11566895stor

Select Create.

Step 2: Enable boot diagnostics on existing virtual machine

To enable Boot diagnostics on an existing virtual machine, follow these steps:

1.Sign in to the Azure portal, and then select the virtual machine VM1.

2. In the Support + troubleshooting section, select Boot diagnostics, then select the Settings tab.

3. In Boot diagnostics settings, change the status to On, and from the Storage account drop-down list, select the storage account az400lod11566895stor.

4. Save the change.

You must restart the virtual machine for the change to take effect.

To configure a virtual machine template in your DevTest Labs environment namedaz400-38443478-dtl1with Windows Server 2016 Datacenter that includes the Selenium tooland the Google Chrome browser, follow these steps:

Create a Custom Image with Windows Server 2016 Datacenter:

In the Azure Portal, go to your DevTest Labaz400-38443478-dtl1.

Navigate toConfiguration and policies>Custom images.

Use an existing VM or create a new one with Windows Server 2016 Datacenter.

After setting up the VM, capture it to create a custom image1.

Install Selenium and Google Chrome on the VM:

Connect to the VM via RDP.

Download and install the Selenium WebDriver for your preferred programming language from the official Selenium website2.

For Google Chrome, download the offline installer from the official website and install it on the VM3.

Generalize the VM:

Run thesysprepcommand to generalize the VM, which prepares it to be used as a template.

Shutdown the VM aftersysprepcompletes.

Capture the Generalized VM to Create a Template:

In the Azure Portal, navigate to the VM and selectCapture.

Provide the required details and create the image.

Add Selenium and Google Chrome Artifacts to the Template:

Go back to the DevTest Labaz400-38443478-dtl1.

SelectArtifactsand add Selenium and Google Chrome artifacts to the template.

Ensure these artifacts are configured to install during the VM creation process.

Create VMs from the Template:

Now, when youcreate a new VM in the DevTest Lab, select the custom image you created.

The VM will be provisioned with Windows Server 2016 Datacenter, and the Selenium tool and Google Chrome browser will be installed automatically.

By following these steps, you can ensure that all virtual machines created from this template in your DevTest Lab will have the required operating system, tools, and browser installed. Remember to replace placeholder names with the actual names of your resources where necessary.

1. Open Microsoft Azure Portal, and select the Azure Container Registry instance named az4009940427acr1.

2. Under Policies, select Content Trust > Enabled > Save.

Task 8: Create a Service Hook to Integrate with Azure Storage (queue1)

Step 1: Verify the Storage Account and Queue

In the Azure portal ( ):

Go to Storage accounts.

Find the storage48901628 storage account.

In the left menu, click on Queues.

Ensure that a queue named queue1 exists.If not, create it by:

Clicking + Queue.

Enter Name: queue1.

Click OK.

Step 2: Prepare the Storage Account’s Shared Access Signature (SAS)

Azure DevOps uses SAS tokens to send messages to a storage queue.

In the Azure portal, go to the storage48901628 storage account.

In the left menu, click Shared access signature.

Set the following:

Allowed services: Queue.

Allowed resource types: Object.

Allowed permissions: Add, Write.

Start and expiry date/time: Adjust as needed (e.g., 1 year).

Click Generate SAS and connection string.

Copy the Queue SAS URL (e.g.,

Step 3: Create the Service Hook in Azure DevOps

In your Azure DevOps Project (Project1):

In the bottom-left, click Project settings.

In the left menu, click Service hooks.

Click + Create subscription.

Step 4: Configure the Azure Storage Service Hook

In the Create a subscription wizard, choose Azure Storage Queues and click Next.

Choose the Trigger:

For example: Code pushed (or other events you want to send to the queue).

Click Next.

Configure the Action:

Queue endpoint URL: The Queue SAS URL you copied in Step 2 (including the queue1 endpoint and SAS token).

Example:

bash

Copy

Step 5: Finalize and Test the Integration

Click Test to ensure Azure DevOps can send a message to the queue.

If the test succeeds, click Finish to create the service hook.

Step 6: Validate in the Azure Portal

In the Azure portal, go to storage48901628 > Queues > queue1.

You should see new messages appear in the queue whenever the configured Azure DevOps event (like push or PR) occurs.
