In Huawei IPTV troubleshooting, mosaic/flash/jerky or intermittent picture typically results from packet loss or bit errors. Common causes include: optical power near the receiver sensitivity threshold causing FEC/BER spikes (A); loss of I-frames (key frames) either in the encoder/compression stage (B) or due to line transmission loss/jitter (D); and device rate-limit (CAR/policing) misconfiguration that drops packets under burst traffic (C). Any of these can yield unstable display.

For Huawei uplink protection (STH-NNI port protection) with workmode timedelay, the mandatory steps are:

Create/define the protection group with the protect-target and workmode timedelay;

Add member ports with roles (work/protect);

Enable the protection group.

Interface-level timers like offline-tx-off-time under the physical interface are not required for standard timedelay protection operation and are therefore optional.

Huawei OLTs support Eth-Trunk (link aggregation) with two standard modes: Static aggregation and Dynamic aggregation (LACP). These provide bandwidth expansion and redundancy on NNI uplinks. “Automatic” is not a defined mode; and “manual” is not used as a separate mode name in OLT Eth-Trunk configuration.

When the number of access users approaches or exceeds the single-layer VLAN space and services must be distinguished per user, Huawei recommends hierarchical VLAN (QinQ) on the uplink: map a customer VLAN (C-VLAN) at the access side and add a service/provider VLAN (S-VLAN) toward the aggregation/core, i.e., C → S+C. This expands scalability beyond the ~4K single-VLAN limit while enabling precise user/service binding for large FTTH deployments (e.g., ~5K users under one OLT).

Huawei access devices apply a deterministic service-flow match order for upstream user packets. VLAN-based matching is attempted first. If no specific service flow matches and TLS (Transparent LAN Service) is configured, the system falls back to the TLS service flow as the default L2 transparent handling for that port/user, ensuring service continuity without explicit per-VLAN bindings.

In IP address discovery mode, eSight does not require L2 same-subnet adjacency; it only requires IP reachability/routing, proper SNMP credentials/alignment, and the operator’s Resource Access permission to poll and add devices. The “same network segment” prerequisite applies to ARP broadcast discovery mode, not to IP address discovery.

In 10G-EPON (IEEE 802.3av), the wavelength plan uses 1577 nm downstream and 1270 nm upstream. The 1270 nm upstream is used in both asymmetric and symmetric 10G-EPON profiles.

This statement is wrong. In U2000, network elements (NEs) can be added by multiple methods, including batch addition/import and automatic discovery, not just one-by-one during a live access session. U2000 supports template-based onboarding and batch operations to improve efficiency for large-scale deployments.

In campus/access networks, IGMP (Internet Group Management Protocol) operates between hosts and the first-hop multicast router/querier on the local subnet. It controls host group membership (Join/Leave/Query/Report), allowing the device to learn which receivers are interested in specific multicast groups and to populate/maintain the local multicast forwarding state.

On Huawei OLTs, the standard QoS pipeline for upstream packets is: first perform traffic classification (identify flows), then marking (set CoS/DSCP as required), next apply traffic policing (rate-limit and color traffic), followed by congestion avoidance (AQM such as RED/WRED), and finally congestion management (queue scheduling/priority queuing). This ordered sequence ensures correct identification and marking before any rate enforcement, and that packets encounter AQM prior to scheduler-based dequeue.

Type C GPON protection uses two different OLTs (dual-home). With uplink status linkage configured, a failure of the active OLT itself or its uplink interface triggers a protection switchover to the standby OLT to maintain service continuity for ONUs homed through the protected ODN.

PITP (Port Identification Transparent Transmission) is used on access networks to carry a user’s physical access-location to the upper AAA/BRAS. It has two working forms: P-mode (PPPoE+)—injecting location identifiers into PPPoE discovery—and V-mode (Vendor-tag)—carrying vendor/location tags transparently upstream. The purpose is to let the upper server associate user credentials with access location and, by policy, restrict roaming. Options A, B, D, and E correctly describe these behaviors/terms. Option C is inaccurate as written: PITP itself does not “bind the authentication” or inherently “avoid theft/roaming”; it only delivers location info. Preventing credential theft/roaming is achieved by AAA/BRAS policy that uses the PITP-carried location, not by PITP alone.

Ethernet VLAN identifiers provide a practical limit of about 4K per broadcast domain. As user counts and services grow toward this boundary, Huawei recommends dual-layer VLAN (QinQ) to extend scale and maintain service isolation. Hence the planning threshold is ~4K.

Type C dual-homing provides device-level protection with two OLTs; when one OLT/uplink fails, services switch to the peer OLT. In single-homing, ONUs are associated with only one OLT; therefore an OLT failure interrupts services (C). Single-homing has simpler networking and management than dual-homing (D). It does not offer switchover to another OLT (so B is incorrect), and the “important-service” positioning in A is typically applied to dual-homing scenarios that require the highest availability.

Huawei multicast guidance stresses IGMP version compatibility: devices running an earlier version must interoperate only with hosts using the same or earlier version, otherwise v3 messages may not be processed. In Huawei’s multicast feature guidance for access devices (OLT side vs. user side), the behavior documented is that when the device is operating in IGMPv2, IGMPv3 Report messages from terminals are not processed—interoperation is restored only after the terminal/device side is downgraded to v2 (often driven by periodic queries that induce hosts to respond in v2). This maps operationally to dropping unsolicited IGMPv3 Reports when the OLT is fixed to v2. Huawei also recommends ensuring the device runs an IGMP version the same as or later than member hosts to avoid such loss. Therefore, with OLT fixed at v2, an incoming v3 Join is discarded.

Type B protection (OLT-side + feeder protection via 2×2 optical splitter) is designed for automatic protection switching (APS) upon detecting faults such as LOS/LOF on the working port or feeder. The system automatically switches to the standby PON port/feeder without manual intervention (manual cutover is optional but not required for protection).

(Reference: HCIP-Access V2.5 – GPON Type A/B/C protection definitions, trigger conditions, and APS behavior.)

The ONT details pane in eSight displays access-port attributes (admin/state, type), Ethernet rate/speed/duplex, and PON optical module telemetry such as temperature and Tx/Rx optical power for condition monitoring and troubleshooting.

For IPv4 multicast, the MAC mapping uses 01-00-5E followed by the low-order 23 bits of the multicast IP address. Because an IPv4 multicast address has 28 variable bits (224/4), 5 bits are not mapped to the MAC. Therefore, 2⁵ = 32 distinct multicast IP addresses can map to the same multicast MAC address.

A single-layer VLAN is limited by the IEEE 802.1Q VLAN ID space (1–4094), i.e., about 4K VLANs. In large PON deployments, when you must separate multiple services (e.g., HSI, VoIP, IPTV) and the user scale approaches or exceeds the 4K ceiling, a dual-layer VLAN (QinQ) design is required to extend the VLAN namespace and implement hierarchical isolation (access VLAN + service/aggregation VLAN).

Huawei GPON service provisioning supports mapping upstream/downstream service flows to GEM Ports using multiple classifiers, including MAC address, physical port (PORT), VLAN ID, and 802.1p (priority). These classifiers are configured in line/service templates (and pushed via U2000) to ensure precise flow-to-GEM binding.

The MG reports availability and restarts to the MGC using H.248 ServiceChange with Method=Restart. The Reason code distinguishes the type of restart. In Huawei implementations aligned with H.248 semantics, Reason=[901] corresponds to a warm/warmboard restart scenario rather than a full cold start.

Board restart triggers a warm restart of the voice board/MG, producing ServiceChange { Method=Restart, Reason=901 }.

Reset coldstart performs a cold start, which would use a different reason code (cold start), not 901.

Reboot system generally implies a broader device reboot similar to cold start semantics, not 901.

ONT re-register affects ONU registration and does not cause the MG to announce a ServiceChange restart to the MGC.

According to IEEE 802.3av wavelength planning adopted by Huawei 10G-EPON, downstream uses 1577 nm and 10G upstream uses 1270 nm. In asymmetric coexistence, 1G-EPON upstream uses 1310 nm, but for 10G-EPON upstream specifically the wavelength is 1270 nm. Therefore the correct upstream wavelength for 10G-EPON is 1270 nm.

Huawei GPON implements hierarchical traffic control. CAR (Committed Access Rate) can be applied at multiple layers: GEM-port level (GEM-CAR), per-flow (Flow-CAR), and T-CONT level (T-CONT-CAR) for upstream bandwidth policing/shaping and guaranteeing QoS. GEM mapping is a classification/association mechanism (service → GEM/T-CONT) rather than a traffic-control action, so it is not a CAR measure.

The statement is wrong. SIP explicitly allows several header fields to appear multiple times within a request or response—for example, Via (one per hop), Route, Record-Route, and Contact may legitimately occur more than once. This is fundamental to SIP routing behavior, where each proxy appends a new Via entry. RFC 3261 explains processing based on the top Via among potentially multiple Via headers, which directly contradicts the claim that “a single information value never appears multiple times

Huawei Anti-MAC-Spoofing binds the source MAC to the service flow/port to prevent address forgery. It is functionally exclusive with certain per-VLAN MAC check features (e.g., WMAC, SC, PPPoe-SMAC) to avoid conflicting validation logic. For IPoE users with fixed IP, operators typically configure static bindings/entries so that address and access policies remain consistent.

Option D is wrong: disabling Anti-MAC-Spoofing and removing fixed entries can affect service behavior; if forwarding is interrupted, that does impact user service—so the statement is self-contradictory and incorrect.

In IP multicast, only one copy per multicast group (program) is forwarded upstream, regardless of how many users are watching it. Replication happens downstream at the access/edge, not toward the core. Therefore the upstream traffic equals the number of active multicast groups × per-group bitrate:

20 programs × 2 Mbit/s = 40 Mbit/s.

This behavior is consistent with Huawei’s multicast feature descriptions and general multicast principles (IGMP/PIM), which explain that multicast traffic is sent as a single flow per group and replicated only where branching occurs, not multiplied by user count.

XGS-PON downstream line rate is ~10 Gbit/s. When 12 terminals share a PON tree concurrently, the rough per-terminal share is 10,000 Mbit/s ÷ 12 ≈ 833 Mbit/s, commonly expressed as “about 800 Mbit/s.” This aligns with planning examples in HCIP-Access where downstream concurrency on XGS-PON is calculated by dividing the port rate by the number of active ONUs/APs on the splitter.

In GPON Type C dual-attribution protection, the ONU has dual PON connections to two OLT PON ports (or two OLTs). When the protection group is configured to track the OLT’s uplink Ethernet port, a Down state on that uplink is an OLT-side trigger. The OLT initiates the protection action (forces the working/standby role swap via PON protection signaling).

A — Correct behavior: After the OLT triggers protection, the ONU’s working PON interface becomes standby, and the protect interface becomes working.

B — Correct behavior: The OLT monitors and updates the ONU uplink status as part of the protection group state machine.

C — Correct behavior: After inversion, services egress the ONU via the protect PON port toward the OLT, i.e., traffic follows the configured protect path.

D — Incorrect (answer): In this scenario the trigger is the OLT’s uplink Ethernet status, not an ONU-detected failure. Therefore the ONU does not detect the fault nor initiate the switchover; the OLT does.

(Reference: HCIP-Access V2.5 – GPON protection mechanisms; Huawei OLT protection group behavior, Type C dual-homing with uplink-tracking.)

Type B provides redundancy with two OLT PON ports on the same OLT and two feeder (backbone) fibers to the ODN. Therefore it protects the PON ports and the backbone/feeder path. It does not protect the OLT itself (still a single OLT) and does not protect the ONU branch fibers.

On Huawei VRP, Advanced IPv4 ACLs (which can match source IP, destination IP, and L4 port numbers) use the 3000–3999 numbering range.

2000–2999 = Basic IPv4 ACL (matches source IP only).

3000–3999 = Advanced IPv4 ACL (matches source/destination IP, protocol, ports).

4000–4999 = Layer 2 (MAC) ACL.

5000–5999 = User-defined/other ranges, not the standard advanced IPv4 range.

Therefore, to match IPs and ports, select 3000–3999.

In Huawei IPTV access, when the OLT’s IGMP audit/authorization debug shows a negative program-rights/authorization result, it indicates that the user lacks permission for the requested multicast program group. This is distinct from port multicast bandwidth alarms (insufficient multicast bandwidth), IGMP snooping state malfunctions, or subscriber traffic shaping/bandwidth checks. Authorization failures map directly to “no permission to watch the program.”

In eSight’s ONT Zero-Touch workflow, multi-service profiles define service parameters delivered to ONTs—primarily service VLANs such as Internet/Data VLAN, Voice VLAN, and IPTV/Multicast VLAN with related QoS. Hardware attributes like ONU type or Ethernet port count are part of the device/ONT profile, not the multi-service profile. A generic “Default VLAN” parameter is not used here; instead, explicit service VLANs are specified (for example, data VLAN and voice VLAN).

In capacity planning, the planned bandwidth is computed as:

Planned Bandwidth = Users × Penetration × Concurrency × Online Bandwidth × Duty Cycle × Channels × Coverage.

Substituting the values: 500 × 0.5 × 0.4 × 4 Mbit/s × 0.125 × 1 × 0.7

= 250 × 0.4 × 4 × 0.125 × 0.7

= 100 × 4 × 0.125 × 0.7

= 400 × 0.125 × 0.7

= 50 × 0.7

= 35 Mbit/s.

This matches the given result, so the statement is true.

XG-PON (10G GPON) adopts XGEM framing. Compared with GPON’s 12-bit GEM Port-ID, XGEM expands the Port-ID field to 16 bits, increasing the number of logical data flows that can be identified per ONU/OLT and improving service granularity. Hence the correct length is 16 bits.
