 This is because an Endpoint Context Server (ECS) is a feature that allows ClearPass to receive contextual information from external sources, such as Aruba Central, and use it for policy enforcement and reporting. An ECS can be configured to point to the Aruba Central API and fetch data such as device type, category, OS, applications, traffic flows, etc.

An ECS can be used to communicate the information that an IoT client has used SSH to Aruba ClearPass Policy Manager (CPPM). The ECS can query the Aruba Central API and retrieve the network traffic flows of the wireless IoT devices that are categorized as “Raspberry Pi” clients. The ECS can then filter the traffic flows by the SSH protocol and send the relevant information to CPPM. CPPM can then use this information for policy decisions, such as allowing or denying SSH access, or triggering alerts or actions.

B. On CPPM enable Device Insight integration. This is not a valid step because Device Insight is a feature that allows ClearPass to discover, profile, and fingerprint devices on the network using deep packet inspection (DPI) and machine learning (ML). Device Insight does not communicate with Aruba Central or receive information from it. Moreover, Device Insight might not be able to detect SSH traffic on encrypted wireless IoT devices without decrypting it first.

C. On Central configure APs and gateways to use CPPM as the RADIUS accounting server. This is not a valid step because RADIUS accounting is a feature that allows network devices to send periodic updates about the status and activity of authenticated users or devices to a RADIUS server, such as CPPM. RADIUS accounting does not communicate with Aruba Central or receive information from it. Moreover, RADIUS accounting might not be able to capture SSH traffic on wireless IoT devices without inspecting it first.

D. On Central set up CPPM as a Webhook application. This is not a valid step because Webhook is a feature that allows Aruba Central to send notifications or events to external applications or services using HTTP requests. Webhook does not communicate with CPPM or send information to it. Moreover, Webhook might not be able to send SSH traffic information on wireless IoT devices without filtering it first.

The exhibit shows the ArubaOS-CX REST API documentation interface, which allows you to explore the available resources and try out the API calls using the “Try it out” button. However, before you can use this feature, you need to authenticate yourself with your Aruba passport account and collect a token that will be used for subsequent requests. This token will expire after a certain time, so you need to refresh it periodically. You can find more details about how to use the documentation interface and collect a token in the ArubaOS-CX REST API Guide1.

According to the ClearPass Policy Manager User Guide1, userAccountControl is a custom attribute in Active Directory that contains a set of flags that define the properties and behavior of user accounts. One of these flags is ACCOUNTDISABLE, which indicates whether the account is disabled or not. By adding this attribute to the filters in the AD authentication source, CPPM can retrieve this attribute for each user and use it as a condition in the enforcement policies to prevent users with disabled accounts from connecting even if they have valid certificates. Therefore, option C is the correct answer.

Alert duration and threshold settings are used to control how often and under what conditions email notifications are sent for gateway IDS/IPS events 1. By adjusting these settings, the customer can reduce the frequency of repeat email notifications for the same threat, while still being informed of any critical or new threats.

To adjust the alert duration and threshold settings in Aruba Central, the customer can follow these steps 1:

• In the Aruba Central app, set the filter to Global, a group, or a device.
• Under Analyze, click Alerts & Events.
• Click the Config icon to open the Alert Severities & Notifications page.
• Select the Gateway IDS/IPS tab to view the alert categories and severities for gateway IDS/IPS events.
• Click on an alert category to expand it and view the alert duration and threshold settings for each severity level.
• Enter a value in minutes for the alert duration. This is the time period during which the alert is active and email notifications are sent.
• Enter a value for the alert threshold. This is the number of times the alert must be triggered within the alert duration before an email notification is sent.
• Click Save.

By increasing the alert duration and/or threshold values, the customer can reduce the number of email notifications for recurring threats, as they will only be sent when the threshold is reached within the duration. For example, if the customer sets the alert duration to 60 minutes and the alert threshold to 10 for a Critical severity level, then an email notification will only be sent if the same threat occurs 10 times or more within an hour.

This is because a parameter is a variable that can be defined and modified by the user or the script, and can be used to customize the behavior and output of the NAE script. A parameter can be referred to by using the syntax self ^ramsfname], where ramsfname is the name of the parameter.

By defining a parameter for the RADIUS server, you can make the NAE script more flexible and adaptable to different scenarios and switches. The parameter can be set to a default value, such as cp.acnsxtest.local, but it can also be changed by the user or the script based on the network conditions and requirements. For example, the user can select a different hostname or IP address for the monitored RADIUS server when they create an agent from the script, or the script can automatically detect and update the parameter based on the switch configuration. This way, the NAE script can monitor statistics from any RADIUS server defined on the switch without hard-coding the server name or IP address in the monitor URI.

A. Use this variable, %{radius-ipV when defining the monitor URI in the NAE agent script. This is not a valid recommendation because %{radius-ipV is not a valid variable in NAE scripts. Variables in NAE scripts are prefixed with self ^ramsfname], not with %. Moreover, radius-ipV is not a predefined variable that contains the RADIUS server name or IP address, but rather a generic term that could refer to any IP version.

C. Use a callback action to collect the name of any RADIUS servers defined on the switch at the time the agent is created. This is not a bad recommendation, but it is not as good as defining a parameter. A callback action is a feature that allows an NAE script to execute a command on the switch and collect its output for further processing or display. A callback action can be used to collect the name of any RADIUS servers defined on the switch by executing a command such as show radius-server or show running-config radius-server and parsing its output. However, a callback action might not be as fast or reliable as using a parameter, as it depends on the availability and responsiveness of the switch and its CLI.

D. Make the script editable so that admins can edit it on demand when they are creating scripts. This is not a good recommendation because making the script editable exposes it to potential errors or modifications that could affect its functionality or performance. Making the script editable also requires more effort and expertise from the admins, who might not be familiar with NAE scripting syntax or logic. Moreover, making the script editable does not future proof it, as it does not allow for dynamic changes or updates based on network conditions or requirements.

10of30

The correct answer is D. Enabling alerts and email notifications for events related to gateway IPS engine utilization and errors.

Gateway IDS/IPS is a feature that allows the Aruba gateways to monitor and block malicious or unwanted traffic based on predefined or custom rules 1. The Fail Strategy is a setting that determines how the gateways handle traffic when the IPS engine fails or crashes 2. The Block option means that the gateways will stop forwarding traffic until the IPS engine recovers, while the Bypass option means that the gateways will continue forwarding traffic without inspection 2.

The Block option provides more security, but it also increases the risk of network outages if the IPS engine fails frequently or for a long time 2. To minimize this risk, it is recommended to enable alerts and email notifications for events related to gateway IPS engine utilization and errors 3. This way, the network administrators can be informed of any issues with the IPS engine and take appropriate actions to restore or troubleshoot it 3.

The other options are not correct or relevant for this issue:

• Option A is not correct because configuring a relatively high threshold for the gateway threat count alerts would not help minimize unexpected outages caused by using the Block option. The gateway threat count alerts are used to notify the network administrators of the number of threats detected by the IPS engine, but they do not affect how the gateways handle traffic when the IPS engine fails 4.
• Option B is not correct because making sure that the gateways have formed a cluster and operate in default gateway mode would not help minimize unexpected outages caused by using the Block option. The gateway cluster mode is used to provide high availability and load balancing for the gateways, but it does not affect how the gateways handle traffic when the IPS engine fails . The default gateway mode is used to enable routing and NAT functions on the gateways, but it does not affect how the gateways handle traffic when the IPS engine fails .
• Option C is not correct because setting the IDS or IPS policy to the least restrictive option, Lenient, would not help minimize unexpected outages caused by using the Block option. The IDS or IPS policy is used to define what rules are applied by the IPS engine to inspect and block traffic, but it does not affect how the gateways handle traffic when the IPS engine fails 2. The Lenient option contains fewer and older rules than the Moderate or Strict options, which means that it provides less security and more false negatives .

The UBT solution requires that the VLAN assignments for the wired clients are done by the gateway, not by the switch. Therefore, the role configurations on the gateways should not have any VLAN assignments, as they would override the VLAN 20 that is specified in the enforcement profile. Instead, the role configurations should only have policies that define the access rights for the clients in the “eth-internet” role. This way, the gateway can assign the clients to VLAN 20 and apply the appropriate policies based on their role1

According to the AOS-CX User Guide, one way to configure the VLAN setting for the reception role is to assign a consistent name to VLAN 14, 24, or 34 on each access layer switch and reference that name in the enforcement profile VLAN settings. This way, the switches can download the role settings from CPPM and apply the correct VLAN based on the name, rather than the ID. For example, the enforcement profile VLAN settings could be:

And the VLAN configuration on each switch could be:

The exhibit shows a screenshot of a Malwarebytes alert that indicates that a website was blocked due to compromise. The alert contains the following information:

• The type of protection: Web Protection
• The website that was blocked: 10.254.1.21
• The port that was used: 80
• The process that initiated the connection: C:\Program Files (x86)\Google\Chrome\Application\chrome.exe
• The IP address of the device that initiated the connection: 10.1.26.151

The IP address of the device that initiated the connection is the one that should be recorded as a possibly compromised client, as it indicates that the device tried to access a malicious website that could infect it with malware or steal its data. In this case, the IP address of the possibly compromised client is 10.1.26.151.

Auto-site clustering is a feature that allows gateways in the same site and group to form a cluster automatically. However, this mode does not support VRRP IP addresses, which are required for dynamic authorization (CoA) from ClearPass Policy Manager (CPPM) to the gateways. Dynamic authorization is a mechanism that allows CPPM to change the attributes or status of a client session on the gateways without requiring re-authentication. This is useful for applying policies, roles, or bandwidth limits based on various conditions. Without VRRP IP addresses, CPPM would not be able to send CoA messages to the correct gateway in case of a failover event, resulting in inconsistent or incorrect client behavior.

To enable VRRP IP addresses for dynamic authorization, you need to set up gateway clusters manually and assign a VRRP VLAN and a VRRP IP address to each cluster. This way, CPPM can use the VRRP IP address as the NAS IP address for RADIUS communications and CoA messages. The VRRP IP address will remain the same even if the active gateway in the cluster changes due to a failover event, ensuring seamless operations. You can find more information about how to set up gateway clusters manually and configure VRRP IP addresses in the Gateway Cluster Deployment - Aruba page and the ClearPass Policy Manager User Guide1.

This is because a downloadable user role (DUR) is a feature that allows the switch to use a central ClearPass server to download user-roles to the switch for authenticated users12 A DUR can contain various attributes and rules that define the access level and privileges of the user, such as VLAN, ACL, PoE, reauthentication period, etc3 A DUR can also be customized and updated on the ClearPass server without requiring any changes on the switch1

A DUR can be used to create a “provision” role that allows users to enroll new wired clients in Intune. The “provision” role can have limited access that only lets them enroll and receive certificates from the Intune service. The “provision” role can also have rules that restrict the Internet access of the users to only the necessary sites, such as the Intune portal and the certificate authority. The rules can be based on IPv4 or IPv6 addresses, depending on the network configuration and preference2

A. Configuring the rules for the “provision” role with IPv6 addresses, which tend to be more stable. This is not a valid recommendation because it does not address how to create and apply the “provision” role on the switch. Moreover, IPv6 addresses do not necessarily tend to be more stable than IPv4 addresses, as both protocols have their own advantages and disadvantages4

B. Enabling tunneling to the MCs on the “provision” role and then setting up the privileges on the MCs. This is not a valid recommendation because it does not explain how to enable tunneling or what MCs are. Moreover, tunneling is a technique that encapsulates one network protocol within another, which adds complexity and overhead to the network communication5

D. Assigning the “provision” role to a VLAN and then setting up the rules within a Layer 2 access control list (ACL). This is not a valid recommendation because it does not explain how to assign a role to a VLAN or how to create a Layer 2 ACL on the switch. Moreover, a Layer 2 ACL is limited in its filtering capabilities, as it can only match on MAC addresses or Ethernet types, which might not be sufficient for restricting Internet access to specific sites

A DNS SAN (Subject Alternative Name) is an extension of the X.509 certificate standard that allows specifying additional hostnames or IP addresses that the certificate can be used for. A DNS SAN is useful for validating the identity of the server or client that presents the certificate, especially when the common name (CN) field does not match the hostname or IP address of the server or client.

In this case, the certificate has a CN of mc41.site94.example.com, which is the fully qualified domain name (FQDN) of the standalone Aruba Mobility Controller (MC). However, this CN may not match the hostname or IP address that the MC uses for the Web UI or for implementing RadSec with Aruba ClearPass Policy Manager. For example, if the MC uses a different FQDN, such as mc41.example.com, or an IP address, such as 192.168.1.41, for these purposes, then the certificate would not be valid for them. Therefore, the certificate should have a DNS SAN that includes all the possible hostnames or IP addresses that the MC may use for the Web UI and RadSec.

The Fail Strategy is a configuration option for the IPS mode of inspection on Aruba gateways. It defines the action to be taken when the IPS engine crashes and cannot inspect the traffic. There are two possible options for the Fail Strategy: Bypass and Block1

If you set the Fail Strategy to Bypass, you are telling the gateway to allow the traffic to flow without inspection when the IPS engine fails. This option ensures that there is no disruption in the network connectivity, but it also exposes the network to potential threats that are not detected or prevented by the IPS engine1

If you set the Fail Strategy to Block, you are telling the gateway to stop the traffic flow until the IPS engine resumes inspection. This option ensures that there is no compromise in the network security, but it also causes a loss of network connectivity for the duration of the IPS engine failure1

Aruba Central supports site-to-site VPNs between AOS 10 gateways, which are Aruba devices that provide routing, firewall, and VPN functions. Aruba Central can automatically provision and manage the site-to-site VPNs using the VPN Manager feature. The VPN Manager allows you to create VPN groups that consist of one or more hubs and branches, and define the VPN settings for each group1

Aruba Central uses IPsec as the protocol to secure the site-to-site connections between the AOS 10 gateways. IPsec is a standard protocol that provides encryption, authentication, and integrity for IP packets. Aruba Central automatically establishes IPsec tunnels for all site-to-site connections using keys that are securely distributed by Central. The keys are generated by Central and pushed to the gateways using a secure channel. The keys are rotated periodically to enhance security2

 This is because this URI specifies the exact attribute that contains the number of access rejects from the RADIUS server, which is the information that the NAE script needs to monitor and trigger an alert.

A. /rest/v1/system/vrfs/mgmt/radius/servers/cp.acnsxtest.local/2083/tcp?attributes=authstatistics. This is not the correct URI because it returns the entire authstatistics object, which contains more information than the access rejects, such as access accepts, challenges, timeouts, etc. This might make the NAE script more complex and inefficient to parse and process the data.

B. /rest/v1/system/vrfs/mgmt/radius/servers/cp.acnsxtest.local/2083/tcp?attributes=authstatistics?attributes=access_rejects. This is not a valid URI because it has two question marks, which is a syntax error. The question mark is used to indicate the start of the query string, which can have one or more parameters separated by ampersands. The correct way to specify multiple attributes is to use a comma-separated list after the question mark, such as ?attributes=attr1,attr2,attr3.

C. /rest/v1/system/vrfs/mgmt/radius/_servers/cp.acnsxtest.local/2083/tcp. This is not a valid URI because it has an extra underscore before servers, which is a typo. The correct resource name is servers, not _servers. Moreover, this URI does not specify any attributes, which means it will return the default attributes of the RADIUS server object, such as name, port, protocol, etc., but not the authstatistics or access_rejects.

7of30

To configure user-based tunneling (UBT) on an AOS-CX switch, you need to specify the IP addresses of the mobility gateways that will receive the tunneled traffic from the switch 1. The primary controller is the preferred gateway for the switch to establish a tunnel, and the backup controller is the alternative gateway in case the primary controller fails or becomes unreachable 1. The IP addresses of the gateways should be their system IP addresses, which are used for inter-controller communication and cluster discovery 2.

In this scenario, the customer has a gateway cluster with two gateways, each with a system IP address on VLAN 4085. Therefore, the switch should use these system IP addresses as the primary and backup controllers for UBT. The IP addresses of the gateways on VLAN 20 and VLAN 4094 are not relevant for UBT, as they are used for user traffic and WAN connectivity, respectively 2. The VRRP IP address on VLAN 20 is also not applicable for UBT, as it is a virtual IP address that is not associated with any specific gateway 3.

Therefore, the best option is to use 10.20.4.21 as the primary controller and 10.20.4.22 as the backup controller for UBT on the switch. This will ensure high availability and cluster discovery for the tunneled traffic from the switch to the gateway cluster 12.
