Goal: enforce captive portal authentication overHTTPSfor guests.

On FortiGate/FortiAuthenticator captive portal setups:

HTTP redirectis used so that when a guest browses to any HTTP site, their request is redirected to theportal URL.

Theportal URLitself must beHTTPSif you want a secure login page.

FortiOS captive portal and firewall authentication guidelines recommend:

EnablingHTTP redirectso unauthenticated HTTP traffic is transparently sent to the portal.

Configuring theportal URL with HTTPS, often referencing a certificate on FortiGate or FortiAuthenticator.

Therefore:

A. Enable HTTP redirect in the user authentication settings.✔This ensures unauthenticated HTTP requests are redirected to the (now HTTPS) portal.

D. Update the captive portal URL to use HTTPS on FortiGate and FortiAuthenticator.✔This makes the login itself secure (TLS-protected).

Incorrect:

B– You don’t need a new SSID; the same SSID can use HTTPS portal.

C– Disabling HTTP admin access on the SSID doesn’t control the captive portal scheme; HTTPS enforcement is done by the portal configuration and redirect, not by admin-access flags.

From the exhibits:

Interface“APs”is a VLAN sub-interface onfortilinkwith IP10.10.100.254/24and a DHCP server scope 10.10.100.1–10.10.100.253.

This VLAN is assigned toport1on the managed FortiSwitch for FortiAPs.

The interface config showsonly allowaccess ping—Security Fabric Connection is not enabled.

In LAN Edge designs, FortiAPs connected through FortiSwitch are discovered and managed asLAN edge devices of the Security Fabric. FortiOS documentation states that FortiAPs and FortiSwitches appear in the Fabric topologyonly when connected on an interface with Security Fabric Connection enabled.

If the VLAN/AP management interface lacksSecurity Fabric Connection:

FortiGate does not treat that network as aFabric connection segment.

CAPWAP discovery from FortiAPs on that VLAN will not result in the AP being onboarded and shown for management.

Therefore the key misconfiguration is:

✔A – Security Fabric is disabled on the VLAN interface used for AP management.

Why the others are not the root cause:

B. Firmware incompatibility– would usually show as a “Managed (upgrade required)” or similar status after discovery, not complete non-detection. The scenario specifically points to a configuration issue, not firmware.

C. VLAN not tagged correctly on uplink– The FortiSwitch uplink to FortiGate is the FortiLink trunk, and the VLAN sub-interface APs is already bound to fortilink, so tagging on the uplink is correct by definition.

D. CAPWAP ports not open– CAPWAP (UDP 5246/5247) is terminated locally on FortiGate and does not depend on any firewall policy; these ports are open on the FortiGate itself by default.

In this design, FortiAuthenticator receivesRADIUS accounting (RSSO) messages, looks up the user in LDAP to get group information, theninjects FSSO logon eventstoward all FortiGate devices.

From the exhibits we know:

FortiAuthenticatoris receiving RADIUS accountingfrom the RADIUS server.

LDAP queries are successful and return group membership.

But FortiGatedoes not receive FSSO logons, so identity-based policies are not applied.

For FortiAuthenticator to create an FSSO logon, the RADIUS accounting record must be correctlyparsed into at least:

Username

Client IP address

These are mapped from the RADIUS attributes in theRADIUS Accounting SSO clientconfiguration (for example, User-Name and Framed-IP-Address). If these are not defined or mapped incorrectly, FortiAuthenticator can see the accounting packet butcannot build a valid FSSO session, so no update is sent to FortiGate.

Thus the most likely root cause is:

✔The RADIUS Username and Client IPv4 attributes are not correctly definedfor that RADIUS Accounting SSO client (optionA).

Other options conflict with the scenario:

B– LDAP is already successfully returning groups.

C– FSSO user group attribute is separate; even without it, FSSO logons would still be created (just without group mapping).

D– The interfaceisreceiving RADIUS accounting, so it is clearly enabled.
