There are three servers in the pool: 172.16.20.1, 172.16.20.2, and 172.16.20.3, with the virtual IP address 10.0.20.88.

A user CANNOT connect to an HTTP application. To understand the problem and find a solution, the LTM Specialist runs two concurrent traces on the LTM device, with the following results:

Trace on client side:

tcpdump: verbose output suppressed, use -v or -vv for full protocol decode

listening on 0.0, link-type EN10MB (Ethernet), capture size 96 bytes

22:22:07.423759 IP 172.16.20.100.53875 > 10.0.20.88.80: S 998346084:998346084(0) win 5840

22:22:07.424056 IP 10.0.20.88.80 > 172.16.20.100.53875: S 4671780:4671780(0) ack 998346085 win 4380

22:22:07.424776 IP 172.16.20.100.53875 > 10.0.20.88.80: . ack 1 win 365

22:22:07.424790 IP 172.16.20.100.53875 > 10.0.20.88.80: P 1:149(148) ack 1 win 365

22:22:07.424891 IP 10.0.20.88.80 > 172.16.20.100.53875: . ack 149 win 4528

22:22:12.024850 IP 10.0.20.88.80 > 172.16.20.100.53875: R 1:1(0) ack 149 win 4528

6 packets captured

6 packets received by filter

0 packets dropped by kernel

Trace on server side:

tcpdump: verbose output suppressed, use -v or -vv for full protocol decode

listening on internal, link-type EN10MB (Ethernet), capture size 96 bytes

22:22:07.424881 IP 172.16.20.100.53875 > 172.16.20.2.80: S 51116678:51116678(0) win 4380

22:22:08.424893 IP 172.16.20.100.53875 > 172.16.20.2.80: S 51116678:51116678(0) win 4380

22:22:09.625082 IP 172.16.20.100.53875 > 172.16.20.2.80: S 51116678:51116678(0) win 4380

22:22:10.825194 IP 172.16.20.100.53875 > 172.16.20.2.80: S 51116678:51116678(0) win 4380

4 packets captured

4 packets received by filter

0 packets dropped by kernel

What should the LTM Specialist do to solve the problem?

An LTM Specialist has a OneConnect profile and HTTP profile configured on a virtual server to load balance an HTTP application.

The following HTTP headers are seen in a network trace when a client connects to the virtual server:

Clientside:

GET / HTTP/1.1

Host: 192.168.136.100

User-Agent: Mozilla/5.0

Accept: text/html,application/xhtml+xml,application/xml;q=0.9,*/*;q=0.8

Accept-EncodinG. gzip, deflate

Connection: keep-alive

Serverside:

HTTP/1.1 200 OK

DatE. 5 Jun 1989 17:06:55 GMT

Server: Apache/2.2.14 (Ubuntu)

Vary: Accept-Encoding

Content-EncodinG. gzip

Content-LengtH. 3729

X-Cnection: close

Content-TypE. text/html

The LTM Specialist notices the OneConnect feature is working incorrectly.

Why is OneConnect functioning incorrectly?

-- Exhibit –

-- Exhibit --

Refer to the exhibit.

Users report that a web application works incorrectly. Sometimes contextual data displayed on the web pages is accurate; other times it is inaccurate.

The LTM administrator looks at the connection table with a filter on one of the client IP addresses currently connected using the command "tmsh show sys connection cs-client-addr 10.0.20.1"

with the following results:

10.0.20.1:60048 10.0.20.88:80 10.0.20.1:60048 172.16.20.1:80 tcp 3 (tmm: 0)

10.0.20.1:60050 10.0.20.88:80 10.0.20.1:60050 172.16.20.3:80 tcp 3 (tmm: 0)

10.0.20.1:60047 10.0.20.88:80 10.0.20.1:60047 172.16.20.2:80 tcp 3 (tmm: 0)

10.0.20.1:60049 10.0.20.88:80 10.0.20.1:60049 172.16.20.1:80 tcp 3 (tmm: 0)

What is the solution to the problem?
