To modify the bar chart to show the percentage of sales for each Subcategory within every Category, you need to do the following steps:

Open the link to Book1 found on the desktop. This will open the Tableau workbook that contains the CategoryPercentage worksheet.

Click on the CategoryPercentage tab at the bottom of the workbook to open the worksheet. You will see a bar chart that shows the total sales for each Subcategory across all Categories.

Right-click on Sales on the Columns shelf and select Add Table Calculation from the menu. This will open a dialog box that allows you to apply a calculation to your measure.

Select Percent of Total from the Calculation Type drop-down list. This will calculate the percentage of sales for each Subcategory out of the total sales for all Subcategories.

Select Category from the Compute Using drop-down list. This will calculate the percentage of sales for each Subcategory within every Category, instead of across all Categories. The total percentage for every Category will be 100%.

Click OK to apply the table calculation. You will see that the bar chart now shows the percentage of sales for each Subcategory within every Category.

To filter the table to show the Top 10 NOC based on the number of medals won, you need to do the following steps:

Open the link to Book1 found on the desktop. This will open the Tableau workbook that contains the Disciplines worksheet.

Click on the Disciplines tab at the bottom of the workbook to open the worksheet. You will see a table that shows the NOC, discipline, and medals for each country.

Drag Medals from the Measures pane to the Filters shelf. This will open a dialog box that allows you to filter by different criteria.

Select Top from the dialog box. This will show you options to filter by the top or bottom values of a field.

Enter 10 in the text box next to By field. This will filter by the top 10 values of Medals.

Select NOC from the drop-down list next to By field. This will filter by the top 10 values of NOC based on Medals.

Click OK to apply the filter. You will see that the table now shows only 10 rows, one for each NOC with the highest number of medals.

To filter the table to show the members of the Top10 set and the Bottom10 set, you need to do the following steps:

Open the link to Book1 found on the desktop. This will open the Tableau workbook that contains the Disciplines worksheet.

Click on the Disciplines tab at the bottom of the workbook to open the worksheet. You will see a table that shows the disciplines, sales, and profit for each salesperson.

Click on the drop-down arrow next to Salesperson on the Filters shelf. This will open a menu that allows you to filter by different criteria.

Select Set from the menu. This will show you the sets that are available for the Salesperson field. You will see Top10 and Bottom10 as two sets that have been created based on the sales ranking.

Check the boxes next to Top10 and Bottom10. This will filter the table to show only the members of these two sets. You can also click on All to deselect all other values.

Click OK to apply the filter. You will see that the table now shows 20 rows, 10 for each set.

To add a distribution band on Profit to show the standard deviation from -1 to 1, you need to do the following steps:

Open the link to Book1 found on the desktop. This will open the Tableau workbook that contains the SalesVSProfit worksheet.

Click on the SalesVSProfit tab at the bottom of the workbook to open the worksheet. You will see a scatter plot that shows the relationship between Sales and Profit for each Sub-Category.

Click on the Analytics tab on the left side of the workbook to open the Analytics pane. You will see a list of analytical objects that you can drag and drop onto your worksheet.

Drag Distribution Band from the Analytics pane to Profit on the Rows shelf. This will add a distribution band on Profit that shows the average and confidence interval for each Sub-Category.

Click on the Edit button on the distribution band to open the Edit Distribution Band dialog box. You will see options to customize your distribution band.

Change the Band From value to -1 and the Band To value to 1. This will change the distribution band to show the standard deviation from -1 to 1, which means one standard deviation below and above the average.

Click OK to apply the changes. You will see that the distribution band now shows a narrower range of values for Profit.
