The ICC mechanical code requires the lowest portion of a floor furnace to have not less than 6 inches (152 mm) clearance from grade level . Therefore, the correct choice is the option corresponding to 6 inches , which is C based on your answer set.

The ICC administrative provisions require construction documents to be submitted in two or more sets with the permit application. After approval, one set is retained by the code official and one set is returned to the applicant to be kept on the job site during construction. That is exactly the condition described in Option D . The code does not state that all sets are retained by the code official or that the purpose is to provide subcontractor copies or backup copies.

Corridor damper testing under the referenced standard requires acceptable closure performance at 150 fpm across the face of the damper. Therefore Option C is correct.

For appliances on roofs, ICC access provisions require a level platform at the appliance. The platform must be not less than 30 inches in any dimension . For the choices provided, that makes 30 inches the correct answer, which is Option C .

Based on the equipment schedule shown in the exhibit, EF-2 is listed with a motor size of 1.5 horsepower . Therefore, the correct answer is C .

Based on the specification sheet shown in the exhibit, the design features state that the optional integral clearance reduction system meets the requirements of NFPA 96 . Therefore, the correct answer is D .

The ICC mechanical administrative inspection sequence includes underground inspection , rough-in inspection , and final inspection as required inspections. An annual system test is not listed as one of the required permit inspections in that section, so Option D is the correct answer. This fits the M2 General Administration content area, which includes permit and inspection administration.

The IFGC rule for above-ground outdoor piping requires piping installed outdoors to be elevated not less than 3 1/2 inches above ground , and where installed across roof surfaces, not less than 3 1/2 inches above the roof surface . Therefore, the correct answer is A .

For indoor combustion air openings, one opening must commence within 12 inches of the top of the enclosure and one within 12 inches of the bottom . That corresponds to 1 foot of the ceiling and 1 foot of the floor , so Option A is correct.

Under the IMC ventilation table, locker/dressing rooms and sports locker rooms are identified with required mechanical exhaust, while spaces such as guard stations do not carry that same exhaust requirement in the table. A high school locker room falls within the locker-room/sports-locker-room category, so Option C is the correct answer. Gambling casinos and office break rooms are provided outdoor air rates, but they are not the required-exhaust space among these listed choices.

Based on the specification sheet shown in the exhibit, the hood is fabricated of Type 430 stainless steel , and the optional stainless steel listed is Type 304 . Therefore, the correct answer is C .

The IMC special exhaust provisions require exhaust outlets terminating at temperatures exceeding 600°F to be designed as a chimney , and the table language identifies this as a single-wall metal chimney . Therefore, Option D is correct.

This question appears to contain a wording issue. In ICC flood-related provisions tied to ventilation/flood openings, the governing limit is that the opening location is not more than 1 foot relative to the reference grade condition used for flood-opening compliance. That corresponds to 1 foot , so Option C is the best-supported answer.

Under the ICC administrative provisions used with the mechanical code, one approved set is retained by the code official, and one approved set is returned to the applicant. The returned set must be kept on the site of the building or job while the authorized work is in progress. That directly matches Option A . It does not require return to the architect, filing with the county clerk, or retention for one year after completion.

ICC mechanical access provisions for appliances in attics require the passageway to be not more than 20 feet in length , measured along the centerline of the passageway from the opening to the appliance, where the attic passageway is the standard reduced-height access condition. Since the attic height given is 66 inches, the standard maximum length applies, so Option C is correct. The 50-foot allowance applies only under a different exception where the passageway is unobstructed and at least 6 feet high for its entire length.
