Cisco 350-501 Exam With Confidence Using Practice Dumps

 MPLS LDP (Label Distribution Protocol) is used for label distribution in MPLS networks. When making changes to the LDP configuration, it’s essential to ensure that the changes do not disrupt existing LDP sessions. In this scenario, the network administrator implemented MPLS LDP changes on the PE-A LSR (Label Switching Router) device, and the goal is to prevent any disruption to LDP peers.

The MPLS LDP Non-Stop Routing (NSR) feature allows LDP sessions to survive control-plane switchover events without interruption. When NSR is enabled, the LDP session state information is synchronized between the active and standby control planes. If the active control plane fails, the standby control plane takes over seamlessly, and LDP sessions continue without interruption.

 The issue is that the R2 Serial 1/0 interface is configured with an IP address, but the R1 Serial 1/0 interface is unnumbered. In OSPF, for two routers to form a neighbor relationship, they must be able to communicate on the same subnet. If one interface is unnumbered and the other has an IP address, they won’t be able to form a neighbor relationship, leading to OSPF prefixes missing from the routing table. References: Implementing and Operating Cisco Service Provider Network Core Technologies (SPCOR) - OSPF Configuration Guide

 The show command output indicates that the BGP neighbor is in an Idle state, which means the BGP session has not been established. Additionally, it mentions “eBGP neighbor with no inbound or outbound policy; defaults to ‘drop’”. This implies that in the absence of specific policies for route advertisement and acceptance, the default action is to drop all routes. Therefore, no routes are accepted from the neighbor 192.168.2.2, nor are any routes advertised to it, aligning with option C. References: = Implementing and Operating Cisco Service Provider Network Core Technologies course materials.
